Product manual:
Air-cooled chillers using advanced production technology, superior quality,
compact structure, beautiful appearance widely used in plastic electroplating
electronic manufacturing pharmaceutical chemical food processing laser
ultrasonic cooling printing industry, can accurately control the modern
industrial mechanized production of the required temperature , Thus greatly
improving the production efficiency and product quality.
Unit features:
1, the compressor used in Japan DAIKIN COPELAND brands such as the United
States compressor, low noise power and durable;
2, the condenser with aluminum fin, heat dissipation effect;
3, all stainless steel water tank evaporator, built-in automatic replenishment
device;
4, selection of imported pumps, stainless steel pump body for customers to
choose, to prevent secondary pollution;
5, the use of microcomputer digital temperature controller, integrated
operation, simple and practical, high control accuracy;
6, the use of box structure, nice, easy to move;
7, the unit configuration is lack of reverse phase protection motor overload protection high and low voltage protection, low temperature protection and other safety protection devices, the system more secure and stable.
AW series of industrial chiller parameters (air-cooled):
Item / model number |
LT-0.6A |
LT-1A |
LT-2A |
LT-3A |
LT-5A |
LT-6A |
LT-8A |
LT-10A |
LT-12A |
LT-15A |
LT-20A |
LT-25A |
LT-30A |
LT-40A |
LT-50A |
|
Standard cooling capacity |
kcal/h 50HZ/60HZ |
1270 |
2400 |
4423 |
6693 |
10983 |
12932 |
17420 |
22695 |
25060 |
35883 |
47331 |
52098 |
71792 |
94198 |
118792 |
KW 50HZ/61HZ |
1.47 |
2.78 |
5.13 |
7.76 |
12.7 |
15 |
20.2 |
26.3 |
29.1 |
41.6 |
54.9 |
60.4 |
83.2 |
109.2 |
137.8 |
|
Enter the total power |
KW |
0.9 |
1.35 |
2.1 |
2.82 |
5 |
5.6 |
7.25 |
9.15 |
11 |
14 |
18.5 |
22 |
30.8 |
37.6 |
48 |
power supply |
1PH-220V 50HZ |
3ph-380v 50HZ |
||||||||||||||
Refrigerant |
name |
R22(R134a/407c) |
||||||||||||||
control method |
Capillary |
External balance thermostatic expansion valve |
||||||||||||||
compressor |
Types |
Fully enclosed scroll type (piston type) |
Fully enclosed scroll |
|||||||||||||
Power (KW) |
0.45 |
0.75 |
1.5 |
2.25 |
3.75 |
4.5 |
6 |
7.5 |
9 |
11.25 |
15 |
18.75 |
22.5 |
30 |
37.5 |
|
Condenser |
Types |
High efficiency copper finned aluminum finned + low noise external rotor fan |
||||||||||||||
Cooling air volume (m3h) |
750 |
1000 |
2000 |
3000 |
5000 |
6000 |
8000 |
10000 |
12000 |
15000 |
20000 |
25000 |
30000 |
40000 |
50000 |
|
Evaporator |
Types |
Water tank coil (shell and tube) |
||||||||||||||
Chilled water (m3 / h) |
0.28 |
0.52 |
1 |
1.42 |
2.4 |
2.8 |
4.2 |
4.62 |
5.4 |
7.6 |
9.8 |
11 |
15 |
20 |
25 |
|
Water tank capacity (L) |
10 |
25 |
30 |
60 |
60 |
70 |
150 |
180 |
270 |
300 |
400 |
400 |
540 |
630 |
720 |
|
Water inlet and outlet pipe diameter |
1/2" |
1/2" |
1/2" |
1" |
1" |
1" |
1-1/2" |
1-1/2" |
2" |
2" |
2" |
2-1/2" |
2-1/2" |
3" |
3" |
|
Water pumps |
Power (KW) |
0.37 |
0.37 |
0.37 |
0.37 |
0.75 |
0.75 |
0.75 |
0.75 |
1.2 |
1.5 |
2.25 |
2.25 |
3.75 |
3.75 |
5.5 |
Yang Cheng (m) |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
20 |
|
safety protection |
Compressor overheating protection, over-current protection, high and low pressure protection, over-temperature protection, flow protection, phase sequence / phase protection, exhaust overheating protection. |
|||||||||||||||
Mechanical Dimensions |
long(MM) |
685 |
680 |
770 |
1000 |
1120 |
1150 |
1250 |
1500 |
1580 |
2080 |
2110 |
2110 |
2300 |
2430 |
2430 |
width(MM) |
400 |
420 |
500 |
480 |
530 |
500 |
680 |
770 |
790 |
780 |
850 |
850 |
930 |
1185 |
1185 |
|
high(MM) |
850 |
850 |
950 |
1100 |
1200 |
1200 |
1350 |
1400 |
1450 |
1650 |
1600 |
1700 |
1650 |
1710 |
1710 |
|
Mechanical dimensions |
kg |
50 |
73 |
95 |
128 |
172 |
190 |
310 |
350 |
510 |
750 |
850 |
950 |
1080 |
1360 |
1550 |
Note: 1. Cooling capacity is based on: chilled water inlet and outlet water temperature 12 ℃ / 7 ℃, cooling water inlet and outlet water temperature 30 ℃ / 35 ℃. 2. Operating range: chilled water temperature range: 5 ℃ to 35 ℃; chilled water temperature difference between 3: 8 ℃; * The right to change these parameters or dimensions without prior notice is reserved.
