Item / model number |
LT-0.6A | LT-1A | LT-2A | LT-3A | LT-5A | LT-6A | LT-8A | LT-10A | LT-12A | LT-15A | LT-20A | LT-25A | LT-30A | LT-40A | LT-50A | |
Standard cooling capacity | kcal/h | 1270 | 2400 | 4423 | 6693 | 10983 | 12932 | 17420 | 22695 | 25060 | 35883 | 47331 | 52098 | 71792 | 94198 | 118792 |
KW | 1.47 | 2.78 | 5.13 | 7.76 | 12.7 | 15 | 20.2 | 26.3 | 29.1 | 41.6 | 54.9 | 60.4 | 83.2 | 109.2 | 137.8 | |
input power | KW | 0.9 | 1.35 | 2.1 | 2.82 | 5 | 5.6 | 7.25 | 9.15 | 11 | 14 | 18.5 | 22 | 30.8 | 37.6 | 48 |
power supply | 1PH-220V 50HZ | 3ph-380v 50HZ | ||||||||||||||
Refrigerant | type | R22(R134a/407c) | ||||||||||||||
control method | Capillary | External balance thermostatic expansion valve | ||||||||||||||
compressor | Types | Fully enclosed scroll type (piston type) | Fully enclosed scroll | |||||||||||||
Power (KW) | 0.45 | 0.75 | 1.5 | 2.25 | 3.75 | 4.5 | 6 | 7.5 | 9 | 11.25 | 15 | 18.75 | 22.5 | 30 | 37.5 | |
Condenser | Types | High efficiency copper finned aluminum finned + low noise external rotor fan |
|
|
||||||||||||
Cooling air volume (m3h) | 750 | 1000 | 2000 | 3000 | 5000 | 6000 | 8000 | 10000 | 12000 | 15000 | 20000 | 25000 | 30000 | 40000 | 50000 | |
Evaporator | Types | Water tank coil (shell and tube) |
|
|
||||||||||||
Chilled water (m3 / h) | 0.28 | 0.52 | 1 | 1.42 | 2.4 | 2.8 | 4.2 | 4.62 | 5.4 | 7.6 | 9.8 | 11 | 15 | 20 | 25 | |
Water tank capacity (L) | 10 | 25 | 30 | 60 | 60 | 70 | 150 | 180 | 270 | 300 | 400 | 400 | 540 | 630 | 720 | |
Water inlet and outlet pipe diameter | 1/2" | 1/2" | 1/2" | 1" | 1" | 1" | 1-1/2" | 1-1/2" | 2" | 2" | 2" | 2-1/2" | 2-1/2" | 3" | 3" | |
Water pumps | Power (KW) | 0.37 | 0.37 | 0.37 | 0.37 | 0.75 | 0.75 | 0.75 | 0.75 | 1.2 | 1.5 | 2.25 | 2.25 | 3.75 | 3.75 | 5.5 |
Yang Cheng (m) | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | 20 | |
safety protection |
|
Compressor overheating protection, over-current protection, high and low pressure protection, over-temperature protection, flow protection, phase sequence / phase protection, exhaust overheating protection. |
|
|
||||||||||||
Mechanical Dimensions | long(MM) | 685 | 680 | 770 | 1000 | 1120 | 1150 | 1250 | 1500 | 1580 | 2080 | 2110 | 2110 | 2300 | 2430 | 2430 |
width(MM) | 400 | 420 | 500 | 480 | 530 | 500 | 680 | 770 | 790 | 780 | 850 | 850 | 930 | 1185 | 1185 | |
high(MM) | 850 | 850 | 950 | 1100 | 1200 | 1200 | 1350 | 1400 | 1450 | 1650 | 1600 | 1700 | 1650 | 1710 | 1710 | |
Mechanical dimensions | kg | 50 | 73 | 95 | 128 | 172 | 190 | 310 | 350 | 510 | 750 | 850 | 950 | 1080 | 1360 | 1550 |
